Load Capacity: 1-500 tons
Minimum Aisle Width: Customized to match on-site aisle dimensions
Platform Size: Customized to fit material dimensions and aisle width
Safety Features: Emergency stop, warning system, anti-collision protection (optional)
Wheels: Cast Steel Polyurethane Rubber Wheel
Movement: 360 ° rotation+lateral/oblique movement (suitable for narrow spaces)
Our company's customized transfer vehicles are specifically designed to match the actual layout, route shape, and space limitations of your facility.
Unlike standard transport vehicles that follow fixed dimensions and straight paths, this vehicle is designed around your usage site and uses materials,
The vehicle structure, turning method, and travel path are customized according to actual site conditions such as channel width, turning radius, obstacles, floor layout, and workstation location, ensuring smooth and uninterrupted movement of materials in complex industrial environments.
Customized content
1. Layout determines design, non-standard size
The design of the factory transfer vehicle is based on the actual geometric shape of your facility, including corridor width, corner angles, work areas, transportation of goods, and other factors.
2. Adapt to turning and turning on irregular routes
In order to adapt to complex on-site routes, electric transfer vehicles can be designed with customized steering or turning structures that align with curved paths, sharp corners, or multi-directional motion requirements.
3. Route specific motion logic
The operating route of the transfer vehicle is set according to a fixed or semi fixed on-site route, which can achieve consistent material flow between workstations even in unconventional facilities.
4. Design of obstacle perception structure
The vehicle height, platform shape, and wheel alignment are all customized to avoid on-site obstacles such as pillars, pits, existing equipment, or height limitations. The design purpose of our company's electric transfer vehicle is to bypass the existing structure, rather than modify the facilities.
360 degree motorized rotation without causing any damage to the floor.
Powered by storage battery, turning freely without any cable strings.
Controlled easily by pressing the buttons and speed controller.
High level automation(self propelled/steerable)
The largest capacity can reach to 100t
Safe parts are installed in the transfer cart(warning light, e-stop, buffer...)
Robust sturdy car frame
