A turntable transfer cart is a heavy-duty rail transfer system designed to move locomotives laterally between parallel tracks. Unlike a conventional transfer cart used for coils, molds, or steel components, it carries railway rails on its deck and moves the rail section to the required track position.
This 200t model is designed for 1520mm gauge locomotive depots and railway workshops. The pit-mounted structure keeps the deck rails flush with the workshop tracks, while the synchronized drive system provides positioning accuracy of up to ±2mm.
Perfect can be customized with different load capacities, platform sizes, navigation systems, and functional configurations to meet specific production requirements.
The following configuration represents a typical heavy-duty turntable transfer cart for locomotive handling:
The final dimensions and rail arrangement are customized according to the locomotive wheelbase, axle loads, track center distances, and pit layout.
Although both systems use heavy-duty transfer cart technology, their working principles are different.
A conventional transfer cart normally has a flat load deck and transports materials such as:
A locomotive turntable transfer cart, however, has railway rails installed on the deck.
The cart itself becomes a temporary section of railway track.
| Feature | Standard Transfer Cart | Turntable Transfer Cart |
| Main purpose | Material transportation | Locomotive track transfer |
| Deck | Steel load deck | Railway track deck |
| Typical load | Coils, molds, machinery | Locomotives and rail vehicles |
| Movement | Along a fixed route | Laterally between parallel tracks |
| Rail alignment | Not normally required | Critical |
| Positioning | General stopping accuracy | ±2mm in this design |
| Installation | Floor or rail mounted | Pit mounted |
The important difference is therefore not simply capacity. A 200t turntable transfer cart must carry the locomotive while maintaining the correct rail geometry and docking position.
A turntable transfer cart combines the functions of a heavy-duty transfer cart and a movable railway track.
Instead of carrying a load directly on a flat steel platform, the cart carries railway rails on its deck. The entire platform moves laterally inside a pit until the rails on the cart are aligned with the selected workshop track.
Once the rails are correctly positioned, the locomotive can travel across the connection.
This makes a turntable transfer cart particularly useful when several parallel railway tracks need to be connected without installing a large number of permanent switches.
The basic operating sequence is:
Locomotive enters → cart moves laterally → rails align → locomotive exits
The transfer movement is controlled by the drive and positioning system rather than by manual track alignment.
The turntable transfer cart carries railway rails on its platform and moves laterally between parallel tracks.
The basic operating sequence is:
Locomotive enters → cart moves laterally → rails align → locomotive exits
Unlike a standard rail transfer cart, the main purpose is not simply to transport a load. The platform itself becomes a temporary section of railway track.
This allows several parallel tracks to be connected without installing additional permanent switches, which can help reduce track layout complexity and save workshop space.
Please feel free to give your inquiry in the form below .We will reply you in 24 hours .
To design a suitable turntable transfer cart, customers should provide:
Indicative price: USD 80,000–140,000 FOB China
Lead time: 10–16 weeks after drawing approval
The price excludes civil works, pit construction, crane lifting, overseas installation, and commissioning travel.
Henan Perfect Handling Equipment Co., Ltd.
Custom 1–1000t rail handling solutions for locomotive depots, railway workshops, and heavy-duty industrial applications.
Built and engineered in Xinxiang, China — the rail handling equipment cluster.
