Load Capacity: 1-500 tons (customized for industrial material handling)
Control mode：Automation control
Certificate: SGS, ISO9001, SASO
Power supply : Low voltage rail, battery, cable reel
Turntable Diameter: Customized (2000–6000 mm)
Rotation Angle: 90° / 180° / 360° (for seamless direction change on rails)
Positioning Accuracy: ±2 mm (for smooth 90° rail alignment)
The turntable track transfer car is a handling assistant that can rotate the track car 90 degrees on the track The rotary transfer car is designed specifically for seamless 90 ° or 360 ° material transfer in track systems, and is widely used in factory workshops, production lines, and heavy-duty material handling environments that require precise alignment and efficient space utilization.
In some transfer sites where tracks are laid, standard track transfer vehicles cannot change direction at intersections and need to occupy additional space to lay turning tracks, which is both troublesome and takes up space,
The turntable transfer car allows another track car to rotate 90 ° or 360 ° in place without the need for additional curved tracks, achieving precise track alignment and smooth direction changes, making it an ideal choice for space limited and intersecting track layouts.
Accurate alignment with the track after angular rotation
Enable vertical and intersecting track layout
Avoiding laying curved tracks can save a lot of space and is convenient and practical
1.Material transfer for production lines with multiple 90 degree directional changes
2.Workshop track system with limited space
3.Heavy load transfer requiring precise track alignment
4.Mold, die and equipment handling
| BXC-2T | BXC-20t | BXC-50t | BXC-100t | BXC-150t | ||
| Rated Load(t) | 2 | 20 | 50 | 100 | 150 | |
| Table Size(mm) | Length(L) | 2000 | 4000 | 5500 | 6500 | 10000 |
| Width(W) | 1500 | 2200 | 2500 | 2800 | 3000 | |
| Heigth(H) | 450 | 550 | 650 | 900 | 1200 | |
| Wheel Base(mm) | 1200 | 2800 | 4200 | 4900 | 7000 | |
| Rail Inner Gauge(mm) | 1200 | 1435 | 1435 | 2000 | 2000 | |
| Wheel Diameter(mm) | 270 | 350 | 500 | 600 | 600 | |
| Wheel Quantity | 4 | 4 | 4 | 4 | 8 | |
| Ground Clearance(mm) | 50 | 50 | 50 | 75 | 75 | |
| Running Speed(min) | 0-25 | 0-20 | 0-20 | 0-20 | 0-18 | |
| Motor Power(kw) | 1 | 2.2 | 5 | 10 | 15 | |
| Battery Capacity | 180 | 180 | 330 | 440 | 600 | |
| Battery Voltage | 24 | 48 | 48 | 72 | 72 | |
| Running Time When Full Load | 4.32 | 4 | 3.3 | 3.2 | 2.9 | |
| Running Distance for One Charge(Km) | 6.5 | 4.8 | 4 | 3.8 | 3.2 | |
| Max Wheel Load(KN) | 14.4 | 77.7 | 174 | 343.8 | 265.2 | |
| Reference Weight(t) | 2.8 | 5.9 | 8 | 14.6 | 26.8 | |
| Recommended Rail Model | P15 | P24 | P43 | QU100 | QU100 | |
360 degree motorized rotation without causing any damage to the floor.
Powered by storage battery, turning freely without any cable strings.
Controlled easily by pressing the buttons and speed controller.
High level automation(self propelled/steerable)
The largest capacity can reach to 100t
Safe parts are installed in the transfer cart(warning light, e-stop, buffer...)
Robust sturdy car frame
Please feel free to give your inquiry in the form below .We will reply you in 24 hours .
Turntable Rail Transfer Cart is suitable for a variety of applications, such as round rails, vertical rails, cross rails, and more.
Turntable Rail Transfer Cart runs smoothly and has high rail connection accuracy, the PLC can be installed to meet fully automated electrical operation.
